The ADDERLink XD641 extends single-head 4K DisplayPort video up to 4096 x 2160 at 60 fps, USB 2.0, and bi-directional audio over a single CATx or fiber cable. The system delivers ultra-high-definition video with 24-bit/96 kHz analog audio plus 8-channel 24-bit/192 kHz PCM audio through DisplayPort connections.
- 4K DisplayPort 1.2 — supports 4096 x 2160 at 60 fps with 8-bit color depth
- USB 2.0 true emulation — four USB-A ports for HID devices with full-speed support
- CATx or fiber transport — single SFP+ port for flexible connectivity options
- Bi-directional audio — analog 3.5mm jacks plus 8-channel digital audio over DisplayPort
- RS232 serial — RJ12 connection with RTS/CTS flow control up to 115,200 baud
Telcordia SR332 Issue 4 March 2016 Calculated @ 55C
10/100 Support
No
Audio In Ports
1× 3.5mm jack
Audio Direction
Bi-directional
Audio Out Ports
2× 3.5mm jack
Serial Standard
RS232
OS Compatibility
All known operating systems
Maximum Baud Rate
115200
Serial Connection
1×
Input Power Supply
PSU 18W
Maximum Resolution
4096 x 2160
Storage Temperature
-10 to 50 °C / 14 to 122 °F
Storage Humidity (%)
0% - 80% (non-condensing)
Construction Material
Robust metal construction
Full Size DisplayPort
2× 1.2
Operating Temperature
0 to 40 °C / 32 to 104 °F
Additional Information
Also supports 8 channels of 24-bit/192kHz PCM audio over the DisplayPort connection
Operating Humidity (%)
0% - 80% (non-condensing)
Temperature Regulation
Fanless
Multi color status LEDs
4×
Power Additional Information
100-240 VAC, 47/63Hz. 12 VDC 18W output from power supply unit
Serial Additional Information
With RTS/CTS flow control
Mean Time Between Failure (MTBF)
500,000 h
Serial Connection Type (console)
RJ12 (6p6c)
Product information and images are compiled from the manufacturer's own publications; they do not depict a Sedan Mühendislik installation. Technical data is confirmed before ordering.
