DF3L is a safety device. It can be used for filling of acetylene cylinders, the device should be placed on the removable pipe, between the distribution pipe and the container to be filled. It can be installed horizontally, vertically or at an angle. It can also be installed on the high pressure side on a C2 H2 supply equipment as defined in ISO 14114. For its non-return function, the DF3L device is placed immediately downstream of the cylinder or bundle. For its fast-action automatic shut-off function, the DF3L is placed upstream of the pressure regulator of the cylinder or supply equipment.
Key features
Equipped with a fast-action automatic shut-off device, which cuts off the gas supply under the effect of an explosion due to decomposition of the acetylene or a flash back
Equipped with a non-return valve, which prevents gas from flowing in the opposite direction to the normal flow
Equipped with a flame arrestor, which prevents a flame from propagating in either direction
Approved by validation test according to EN ISO 15615
Product information and images are compiled from the manufacturer's own publications; they do not depict a Sedan Mühendislik installation. Technical data is confirmed before ordering.
