π0029 (according to TPED), manufacturing date, 3 stars, valve part number, valve inlet, valve outlet
Leak rate
<1.10 -3 m bar L/s
Connections
According (inter-)national standards and customer’s specifications
Body materials
Stainless steel 1.4435 (AISI 316L)
Working pressure
300 bar
Nominal flow rate
CV = max. 1.8 or 1.5
Seat orifice size
12 Mm
Temperature range
-20 to +65 °c
Product information and images are compiled from the manufacturer's own publications; they do not depict a Sedan Mühendislik installation. Technical data is confirmed before ordering.
